Magnaflux Spotcheck SKL-SP2 Penetrant - 55 Gallons
Solvent Removable Visible Penetrant
SKL-SP2 is a solvent removable penetrant for portability, especially for welding operations, and is post emulsifiable for greater resolution of flaw indications. It produces a visible red color contrast, and features outstanding penetrating characteristics.
SKL-SP2 is highly reliable at locating surface open flaws and discontinuities and can be used on non-porous ceramics and similar materials. Typically used on welds, forgings, pressure vessels, castings, general metal work, leak testing, and in power plants and construction applications.
SKL-SP2 is listed on the QPL SAE AMS 2644 Qualified Product List.
Benefits
- Outstanding penetrating characteristics
- Vivid, high-contrast color
- Superior flaw resolution
- Excellent reliability
Specifications
- AECL
- AMS 2644
- ASME
- ASTM E1417
- ASTM E165
- ISO 3452
- MIL-STD-2132
- MIL-STD-271
- NAVSEA T9074-AS-GIB-010/271
- NAVSEA 250-1500-1
- QPL SAE AMS 2644
Applications
Defect location: open to surface
Ideal for:
- Wide range of applications
- Castings
- Forgings
- Welds
- Pressure vessels
- Tubular goods
- Non-porous ceramics
- General metal work
- Leak testing
- Power generating plants
- Construction applications
Defect examples:
- Cracks
- Leaks
Use Recommendations
NDT Method: Penetrant Testing, Visible / Color-Contrast
Type: Type 2
Methods: Method B, Method C or Method D
Temperature Range: 40 to 125°F / 4 to 52°C
Container Size & Part Number
Aerosol can, case of 12 01-5155-78
1 gal / 3.78 L jug, case of 4 01-5155-35
5 gal / 18.9 L pail 01-5155-40
55 gal / 208 L drum 01-5155-45
